The Soverel 26 1975 is a 26.2ft masthead sloop designed by Mark Soverel and built in fiberglass by Soverel Marine (USA) since 1975.
25 units have been built.
The Soverel 26 1975 is a light sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Soverel 26 1975 | ||
| Length | 26.20 ft | ||
| Beam | 10.10 ft | ||
| Draft | 4.60 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.85 | ||
| Ballast / displ. | 42.11 % | ||
| Displ. / length | 155.33 | ||
| Comfort ratio | 13.72 | ||
| Capsize | 2.41 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23.90 ft | ||
| Maximum draft | 4.60 ft | ||
| Displacement | 4750 lbs | ||
| Ballast | 2000 lbs | ||
| Hull speed | 6.55 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 332 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 194.40 sq.ft | ||
| Sail area main | 137.95 sq.ft | ||
| I | 36 ft | ||
| J | 10.80 ft | ||
| P | 31 ft | ||
| E | 8.90 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Soverel Marine (USA) | ||
| Designer | Mark Soverel | ||
| First built | 1975 | ||
| Last built | 0 | ?? | |
| Number built | 25 |
