Block island 40 migrator
The Block island 40 migrator is a 40.75ft masthead yawl designed by William Tripp Jr. and built in fiberglass since 1984.
The Block island 40 migrator is a heavy sailboat which is slightly under powered. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat.
Block island 40 migrator for sale elsewhere on the web:
Main features
| Model | Block island 40 migrator | ||
| Length | 40.75 ft | ||
| Beam | 11 ft | ||
| Draft | 4.20 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.41 | ||
| Ballast / displ. | 39 % | ||
| Displ. / length | 355.69 | ||
| Comfort ratio | 38.75 | ||
| Capsize | 1.62 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 29.28 ft | ||
| Maximum draft | 8.82 ft | ||
| Displacement | 20000 lbs | ||
| Ballast | 7800 lbs | ||
| Hull speed | 7.25 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Yawl | ||
| Sail area (100%) | 661 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 364.57 sq.ft | ||
| Sail area main | 296.25 sq.ft | ||
| I | 46.80 ft | ||
| J | 15.58 ft | ||
| P | 39.50 ft | ||
| E | 15 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | William Tripp Jr. | ||
| First built | 1984 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
