The Singoalla 34 albin is a 33.67ft masthead sloop designed by Per Brohäll and built in fiberglass by Albin Marine since 1970.
The Singoalla 34 albin is a light sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Singoalla 34 albin | ||
| Length | 33.67 ft | ||
| Beam | 10.82 ft | ||
| Draft | 5.17 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.84 | ||
| Ballast / displ. | 42.52 % | ||
| Displ. / length | 192.89 | ||
| Comfort ratio | 19.55 | ||
| Capsize | 2.10 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 27.33 ft | ||
| Maximum draft | 5.17 ft | ||
| Displacement | 8820 lbs | ||
| Ballast | 3750 lbs | ||
| Hull speed | 7.01 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 501 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 282.15 sq.ft | ||
| Sail area main | 220.18 sq.ft | ||
| I | 41.34 ft | ||
| J | 13.65 ft | ||
| P | 34.43 ft | ||
| E | 12.79 ft |
Engine
| Nb engines | 1 | ||
| Total power | 22 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Albin Marine | ||
| Designer | Per Brohäll | ||
| First built | 1970 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
