The Sigma 36 thomas is a 36.0ft fractional sloop designed by David Thomas and built in fiberglass since 1979.
The Sigma 36 thomas is a moderate weight sailboat which is a good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Sigma 36 thomas | ||
| Length | 36 ft | ||
| Beam | 11.50 ft | ||
| Draft | 6.42 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.18 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 232.01 | ||
| Comfort ratio | 23.86 | ||
| Capsize | 1.99 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 28.75 ft | ||
| Maximum draft | 6.42 ft | ||
| Displacement | 12350 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 7.18 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 605 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 260.35 sq.ft | ||
| Sail area main | 344.25 sq.ft | ||
| I | 41 ft | ||
| J | 12.70 ft | ||
| P | 45 ft | ||
| E | 15.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 23 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | David Thomas | ||
| First built | 1979 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
