The Shipman 50 is a 49.16ft fractional sloop designed by J&J Design and built in fiberglass by Shipman since 2001.
11 units have been built.
The Shipman 50 is a light sailboat which is under powered. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Shipman 50 | ||
| Length | 49.16 ft | ||
| Beam | 14.75 ft | ||
| Draft | 7.75 ft | ||
| Country | Slovenia (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 0 | ?? | |
| Ballast / displ. | 0 % | ||
| Displ. / length | 140.22 | ||
| Comfort ratio | 26.90 | ||
| Capsize | 1.92 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 45.25 ft | ||
| Maximum draft | 7.75 ft | ||
| Displacement | 29101 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 9.01 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 0 sq.ft | ?? | |
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 75 HP | ||
| Fuel capacity | 89 gals |
Accommodations
| Water capacity | 127 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Shipman | ||
| Designer | J&J Design | ||
| First built | 2001 | ||
| Last built | 0 | ?? | |
| Number built | 11 |
