The Shipman 28 is a 29.06ft masthead sloop designed by Olle Enderlein and built in fiberglass by Shipman between 1969 and 1979.
1000 units have been built.
The Shipman 28 is a heavy sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Shipman 28 | ||
| Length | 29.06 ft | ||
| Beam | 8.53 ft | ||
| Draft | 5.09 ft | ||
| Country | Slovenia (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.90 | ||
| Ballast / displ. | 40.32 % | ||
| Displ. / length | 318.83 | ||
| Comfort ratio | 25.11 | ||
| Capsize | 1.82 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 21 ft | ||
| Maximum draft | 5.09 ft | ||
| Displacement | 6614 lbs | ||
| Ballast | 2667 lbs | ||
| Hull speed | 6.14 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 349 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 187.08 sq.ft | ||
| Sail area main | 161.80 sq.ft | ||
| I | 35.10 ft | ||
| J | 10.66 ft | ||
| P | 31.82 ft | ||
| E | 10.17 ft |
Engine
| Nb engines | 1 | ||
| Total power | 12 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Shipman | ||
| Designer | Olle Enderlein | ||
| First built | 1969 | ||
| Last built | 1979 | ||
| Number built | 1000 |
