Seidelmann 30 t
The Seidelmann 30 t is a 29.92ft masthead sloop designed by Bob Seidelmann and built in fiberglass by Seidelmann Yachts since 1977.
The Seidelmann 30 t is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Seidelmann 30 t for sale elsewhere on the web:
Main features
| Model | Seidelmann 30 t | ||
| Length | 29.92 ft | ||
| Beam | 11 ft | ||
| Draft | 5.42 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.82 | ||
| Ballast / displ. | 40.91 % | ||
| Displ. / length | 284.18 | ||
| Comfort ratio | 21.64 | ||
| Capsize | 2.13 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 24 ft | ||
| Maximum draft | 5.42 ft | ||
| Displacement | 8800 lbs | ||
| Ballast | 3600 lbs | ||
| Hull speed | 6.56 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 420 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 234 sq.ft | ||
| Sail area main | 189.75 sq.ft | ||
| I | 39 ft | ||
| J | 12 ft | ||
| P | 33 ft | ||
| E | 11.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 15 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 30 gals | ||
| Headroom | 6.42 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Seidelmann Yachts | ||
| Designer | Bob Seidelmann | ||
| First built | 1977 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
