The Seidelmann 25 is a 24.6ft masthead sloop designed by Bob Seidelmann and built in fiberglass by Seidelmann Yachts since 1977.
The Seidelmann 25 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Seidelmann 25 | ||
| Length | 24.60 ft | ||
| Beam | 9.50 ft | ||
| Draft | 4.33 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.30 | ||
| Ballast / displ. | 47.83 % | ||
| Displ. / length | 256.70 | ||
| Comfort ratio | 16.58 | ||
| Capsize | 2.29 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20 ft | ||
| Maximum draft | 4.33 ft | ||
| Displacement | 4600 lbs | ||
| Ballast | 2200 lbs | ||
| Hull speed | 5.99 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 281 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 169.26 sq.ft | ||
| Sail area main | 112.50 sq.ft | ||
| I | 31 ft | ||
| J | 10.92 ft | ||
| P | 25 ft | ||
| E | 9 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Seidelmann Yachts | ||
| Designer | Bob Seidelmann | ||
| First built | 1977 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
