The Seafarer 26 is a 25.75ft masthead sloop designed by McCurdy and Rhodes and built in fiberglass by Seafarer Yachts since 1977.
The Seafarer 26 is a light sailboat which is slightly under powered. It is stable / stiff and has a good righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Seafarer 26 | ||
| Length | 25.75 ft | ||
| Beam | 8.25 ft | ||
| Draft | 3.75 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.66 | ||
| Ballast / displ. | 38.59 % | ||
| Displ. / length | 174.41 | ||
| Comfort ratio | 18.08 | ||
| Capsize | 1.99 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 22.75 ft | ||
| Maximum draft | 3.75 ft | ||
| Displacement | 4600 lbs | ||
| Ballast | 1775 lbs | ||
| Hull speed | 6.39 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 270 sq.ft | ||
| Air draft | 33.92 ft | ||
| Sail area fore | 162.41 sq.ft | ||
| Sail area main | 107.31 sq.ft | ||
| I | 30.50 ft | ||
| J | 10.65 ft | ||
| P | 25.25 ft | ||
| E | 8.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 43 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Seafarer Yachts | ||
| Designer | McCurdy and Rhodes | ||
| First built | 1977 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
