The Schock 40 is a 40.0ft masthead sloop designed by DynaYacht and built in fiberglass by Schock W.D. since 2000.
10 units have been built.
The Schock 40 is an ultralight sailboat which is a very high performer. It is not stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Schock 40 | ||
| Length | 40 ft | ||
| Beam | 10 ft | ||
| Draft | 8 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Find boats for sale with Sailboatlab Market Analyst
Ratios
| Sail area / displ. | 29.91 | ||
| Ballast / displ. | 25.71 % | ||
| Displ. / length | 72.89 | ||
| Comfort ratio | 13.80 | ||
| Capsize | 2.09 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 35 ft | ||
| Maximum draft | 8 ft | ||
| Displacement | 7000 lbs | ||
| Ballast | 1800 lbs | ||
| Hull speed | 7.93 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 682 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 288.58 sq.ft | ||
| Sail area main | 393.16 sq.ft | ||
| I | 42.50 ft | ||
| J | 13.58 ft | ||
| P | 44.50 ft | ||
| E | 17.67 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 12 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Schock W.D. | ||
| Designer | DynaYacht | ||
| First built | 2000 | ||
| Last built | 0 | ?? | |
| Number built | 10 |
