The Scanper 22 is a 22.24ft fractional sloop designed by Peter Norlin/Bernt Lindquist and built in fiberglass by Fabola Boats (SWE) between 1976 and 1980.
100 units have been built.
The Scanper 22 is a light sailboat which is slightly under powered. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Scanper 22 | ||
| Length | 22.24 ft | ||
| Beam | 8.20 ft | ||
| Draft | 4.27 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.82 | ||
| Ballast / displ. | 39.32 % | ||
| Displ. / length | 187.25 | ||
| Comfort ratio | 14.65 | ||
| Capsize | 2.23 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 19.68 ft | ||
| Maximum draft | 4.27 ft | ||
| Displacement | 3197 lbs | ||
| Ballast | 1257 lbs | ||
| Hull speed | 5.94 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 214 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 109.14 sq.ft | ||
| Sail area main | 104.64 sq.ft | ||
| I | 25.59 ft | ||
| J | 8.53 ft | ||
| P | 27.72 ft | ||
| E | 7.55 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Fabola Boats (SWE) | ||
| Designer | Peter Norlin/Bernt Lindquist | ||
| First built | 1976 | ||
| Last built | 1980 | ||
| Number built | 100 |
