The Saona 47 is a 46.0ft fractional sloop designed by Berret Racoupeau Yacht Design and built in fiberglass by Fountaine Pajot since 2016.
The Saona 47 is a light sailboat which is under powered. The fuel capacity is excellent. There is a good water supply range.
Main features
| Model | Saona 47 | ||
| Length | 46 ft | ||
| Beam | 25.30 ft | ||
| Draft | 4.20 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 13.30 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 139.54 | ||
| Comfort ratio | 13.85 | ||
| Capsize | 3.24 |
Hull
| Hull type | Catamaran Twin Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 46 ft | ||
| Maximum draft | 4.20 ft | ||
| Displacement | 30424 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 9.09 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 807 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 100 HP | ||
| Fuel capacity | 248 gals |
Accommodations
| Water capacity | 185 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Fountaine Pajot | ||
| Designer | Berret Racoupeau Yacht Design | ||
| First built | 2016 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
