The Sanya 57 is a 56.63ft frac. sloop (rotating spar) designed by Berret Racoupeau Yacht Design and built in fiberglass by Fountaine Pajot since 2010.
It accomodates 14 people in 6 cabins plus salon.
The Sanya 57 is a light sailboat which is slightly under powered. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Sanya 57 | ||
| Length | 56.63 ft | ||
| Beam | 29.13 ft | ||
| Draft | 4.59 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.58 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 138.43 | ||
| Comfort ratio | 16.82 | ||
| Capsize | 3.07 |
Hull
| Hull type | Catamaran Twin Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 56 ft | ||
| Maximum draft | 4.59 ft | ||
| Displacement | 54454 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 10.03 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Frac. Sloop (Rotating Spar) | ||
| Sail area (100%) | 1398 sq.ft | ||
| Air draft | 75.50 ft | ||
| Sail area fore | 699.65 sq.ft | ||
| Sail area main | 1184 sq.ft | ||
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 2 | ||
| Total power | 110 HP | ||
| Fuel capacity | 290 gals |
Accommodations
| Water capacity | 277 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 6 | ||
| Nb of berths | 14 | ||
| Nb heads | 6 | ?? |
Builder data
| Builder | Fountaine Pajot | ||
| Designer | Berret Racoupeau Yacht Design | ||
| First built | 2010 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
