The Santana 21 is a 21.25ft fractional sloop designed by Seymour Paul and built in fiberglass by Schock W.D. between 1969 and 1976.
879 units have been built.
The Santana 21 is a light sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Santana 21 | ||
| Length | 21.25 ft | ||
| Beam | 7.50 ft | ||
| Draft | 1.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.29 | ||
| Ballast / displ. | 32.35 % | ||
| Displ. / length | 105.08 | ||
| Comfort ratio | 9.01 | ||
| Capsize | 2.52 |
Hull
| Hull type | Monohull swing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 19.33 ft | ||
| Maximum draft | 2.50 ft | ||
| Displacement | 1700 lbs | ||
| Ballast | 550 lbs | ||
| Hull speed | 5.89 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 198 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 111.63 sq.ft | ||
| Sail area main | 86 sq.ft | ||
| I | 23.50 ft | ||
| J | 9.50 ft | ||
| P | 21.50 ft | ||
| E | 8 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Schock W.D. | ||
| Designer | Seymour Paul | ||
| First built | 1969 | ||
| Last built | 1976 | ||
| Number built | 879 |
