The Sangria 25 jeanneau is a 25.0ft masthead sloop designed by Philippe Harlé and built in fiberglass by Jeanneau (FRA) between 1969 and 1982.
2150 units have been built.
The Sangria 25 jeanneau is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Sangria 25 jeanneau | ||
| Length | 25 ft | ||
| Beam | 8.86 ft | ||
| Draft | 4.10 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Find boats for sale with Sailboatlab Market Analyst
Ratios
| Sail area / displ. | 16.26 | ||
| Ballast / displ. | 41.66 % | ||
| Displ. / length | 257.04 | ||
| Comfort ratio | 16.11 | ||
| Capsize | 2.24 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 19.03 ft | ||
| Maximum draft | 4.10 ft | ||
| Displacement | 3968 lbs | ||
| Ballast | 1653 lbs | ||
| Hull speed | 5.85 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 254 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 137.94 sq.ft | ||
| Sail area main | 116.45 sq.ft | ||
| I | 30.02 ft | ||
| J | 9.19 ft | ||
| P | 25.26 ft | ||
| E | 9.22 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 11 gals |
Accommodations
| Water capacity | 26 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Philippe Harlé | ||
| First built | 1969 | ||
| Last built | 1982 | ||
| Number built | 2150 |
