The San juan 34 is a 33.79ft masthead sloop designed by Hein Driehuyzen/Don Clark and built in fiberglass by Clark Boat Company between 1980 and 1986.
The San juan 34 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | San juan 34 | ||
| Length | 33.79 ft | ||
| Beam | 10.92 ft | ||
| Draft | 5.92 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.35 | ||
| Ballast / displ. | 45.71 % | ||
| Displ. / length | 215.37 | ||
| Comfort ratio | 22.64 | ||
| Capsize | 2 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 27.92 ft | ||
| Maximum draft | 5.92 ft | ||
| Displacement | 10500 lbs | ||
| Ballast | 4800 lbs | ||
| Hull speed | 7.08 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 548 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 331.68 sq.ft | ||
| Sail area main | 217.25 sq.ft | ||
| I | 45.25 ft | ||
| J | 14.66 ft | ||
| P | 39.50 ft | ||
| E | 11 ft |
Engine
| Nb engines | 1 | ||
| Total power | 24 HP | ||
| Fuel capacity | 22 gals |
Accommodations
| Water capacity | 50 gals | ||
| Headroom | 6.25 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Clark Boat Company | ||
| Designer | Hein Driehuyzen/Don Clark | ||
| First built | 1980 | ||
| Last built | 1986 | ||
| Number built | 0 | ?? |
