Beneteau 46
The Beneteau 46 is a 47.25ft fractional sloop designed by Berret Racoupeau Yacht Design and built in fiberglass by Beneteau since 2005.
The Beneteau 46 is a light sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a good water supply range.
Beneteau 46 for sale elsewhere on the web:
Main features
| Model | Beneteau 46 | ||
| Length | 47.25 ft | ||
| Beam | 13.92 ft | ||
| Draft | 5.75 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.31 | ||
| Ballast / displ. | 30.67 % | ||
| Displ. / length | 162.47 | ||
| Comfort ratio | 25.60 | ||
| Capsize | 1.95 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 40 ft | ||
| Maximum draft | 5.75 ft | ||
| Displacement | 23292 lbs | ||
| Ballast | 7143 lbs | ||
| Hull speed | 8.47 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1055 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 442.68 sq.ft | ||
| Sail area main | 436.20 sq.ft | ||
| I | 53.92 ft | ||
| J | 16.42 ft | ||
| P | 50.08 ft | ||
| E | 17.42 ft |
Engine
| Nb engines | 1 | ||
| Total power | 54 HP | ||
| Fuel capacity | 53 gals |
Accommodations
| Water capacity | 150 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Beneteau | ||
| Designer | Berret Racoupeau Yacht Design | ||
| First built | 2005 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
