The S2 103 is a 33.75ft masthead sloop designed by Graham & Schlageter and built in fiberglass by S2 Yachts (USA) between 1982 and 1987.
45 units have been built.
The S2 103 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | S2 103 | ||
| Length | 33.75 ft | ||
| Beam | 11.33 ft | ||
| Draft | 6.16 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.88 | ||
| Ballast / displ. | 42.86 % | ||
| Displ. / length | 213.53 | ||
| Comfort ratio | 21.53 | ||
| Capsize | 2.07 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 28 ft | ||
| Maximum draft | 6.16 ft | ||
| Displacement | 10500 lbs | ||
| Ballast | 4500 lbs | ||
| Hull speed | 7.09 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 564 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 303.75 sq.ft | ||
| Sail area main | 260 sq.ft | ||
| I | 45 ft | ||
| J | 13.50 ft | ||
| P | 40 ft | ||
| E | 13 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | S2 Yachts (USA) | ||
| Designer | Graham & Schlageter | ||
| First built | 1982 | ||
| Last built | 1987 | ||
| Number built | 45 |
