The Robb 35 is a 35.5ft masthead sloop designed by Arthur Robb and built in wood by Cheoy Lee Shipyard since 1961.
The Robb 35 is a very heavy sailboat which is slightly under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Robb 35 | ||
| Length | 35.50 ft | ||
| Beam | 10 ft | ||
| Draft | 4.67 ft | ||
| Country | Hong Kong (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.58 | ||
| Ballast / displ. | 31.59 % | ||
| Displ. / length | 480.53 | ||
| Comfort ratio | 39.01 | ||
| Capsize | 1.63 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Wood | ||
| Waterline length | 24 ft | ||
| Maximum draft | 4.67 ft | ||
| Displacement | 14880 lbs | ||
| Ballast | 4700 lbs | ||
| Hull speed | 6.56 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 587 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 287 sq.ft | ||
| Sail area main | 296 sq.ft | ||
| I | 41 ft | ||
| J | 14 ft | ||
| P | 37 ft | ||
| E | 16 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 30 gals |
Accommodations
| Water capacity | 80 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Cheoy Lee Shipyard | ||
| Designer | Arthur Robb | ||
| First built | 1961 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
