The Rl 24 is a 24.0ft fractional sloop designed by Rob Legg and built in fiberglass by Rob Legg Yachts Ltd. between 1973 and 1987.
500 units have been built.
The Rl 24 is an ultralight sailboat which is a very high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Rl 24 | ||
| Length | 24 ft | ||
| Beam | 7.33 ft | ||
| Draft | 1 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 24.80 | ||
| Ballast / displ. | 13.64 % | ||
| Displ. / length | 99.34 | ||
| Comfort ratio | 8.61 | ||
| Capsize | 2.48 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 19.50 ft | ||
| Maximum draft | 4.25 ft | ||
| Displacement | 1650 lbs | ||
| Ballast | 225 lbs | ||
| Hull speed | 5.92 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 216 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Rob Legg Yachts Ltd. | ||
| Designer | Rob Legg | ||
| First built | 1973 | ||
| Last built | 1987 | ||
| Number built | 500 |
