The Renown 32 westerly is a 32.5ft masthead sloop designed by Laurent Giles and partners ltd and built in fiberglass by Westerly Marine Construction Ltd. between 1972 and 1980.
241 units have been built.
The Renown 32 westerly is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Renown 32 westerly | ||
| Length | 32.50 ft | ||
| Beam | 9.50 ft | ||
| Draft | 4.50 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.94 | ||
| Ballast / displ. | 45.98 % | ||
| Displ. / length | 280.96 | ||
| Comfort ratio | 25.24 | ||
| Capsize | 1.85 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 24 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 8700 lbs | ||
| Ballast | 4000 lbs | ||
| Hull speed | 6.56 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 420 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 212.80 sq.ft | ||
| Sail area main | 206.70 sq.ft | ||
| I | 38 ft | ||
| J | 11.20 ft | ||
| P | 31.80 ft | ||
| E | 13 ft |
Engine
| Nb engines | 1 | ||
| Total power | 25 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Westerly Marine Construction Ltd. | ||
| Designer | Laurent Giles and partners ltd | ||
| First built | 1972 | ||
| Last built | 1980 | ||
| Number built | 241 |
