The Reliance 12 is a 39.33ft fractional sloop designed by Steve Killing and built in fiberglass between 1987 and 1988.
5 units have been built.
The Reliance 12 is a light sailboat which is a good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Reliance 12 | ||
| Length | 39.33 ft | ||
| Beam | 8.33 ft | ||
| Draft | 6.08 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.24 | ||
| Ballast / displ. | 56.18 % | ||
| Displ. / length | 147.16 | ||
| Comfort ratio | 24.90 | ||
| Capsize | 1.61 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 30 ft | ||
| Maximum draft | 6.08 ft | ||
| Displacement | 8900 lbs | ||
| Ballast | 5000 lbs | ||
| Hull speed | 7.34 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 488 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 228 sq.ft | ||
| Sail area main | 260 sq.ft | ||
| I | 38 ft | ||
| J | 12 ft | ||
| P | 40 ft | ||
| E | 13 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Steve Killing | ||
| First built | 1987 | ||
| Last built | 1988 | ||
| Number built | 5 |
