The Rasmus 35 hallberg rassy is a 34.5ft masthead sloop designed by Olle Enderlein and built in fiberglass by Hallberg Rassy between 1967 and 1978.
760 units have been built.
The Rasmus 35 hallberg rassy is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a short water supply range.
Main features
| Model | Rasmus 35 hallberg rassy | ||
| Length | 34.50 ft | ||
| Beam | 10 ft | ||
| Draft | 4.25 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.59 | ||
| Ballast / displ. | 45.45 % | ||
| Displ. / length | 257.49 | ||
| Comfort ratio | 29.36 | ||
| Capsize | 1.75 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 27.58 ft | ||
| Maximum draft | 4.25 ft | ||
| Displacement | 12100 lbs | ||
| Ballast | 5500 lbs | ||
| Hull speed | 7.04 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 479 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 234 sq.ft | ||
| Sail area main | 245 sq.ft | ||
| I | 39 ft | ||
| J | 12 ft | ||
| P | 35 ft | ||
| E | 14 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 63 gals |
Accommodations
| Water capacity | 70 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hallberg Rassy | ||
| Designer | Olle Enderlein | ||
| First built | 1967 | ||
| Last built | 1978 | ||
| Number built | 760 |
