The Quickstep 24 is a 23.92ft masthead sloop designed by Ted Brewer and built in fiberglass by Shannon Yachts between 1976 and 1989.
200 units have been built.
The Quickstep 24 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Quickstep 24 | ||
| Length | 23.92 ft | ||
| Beam | 7.92 ft | ||
| Draft | 3.37 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.49 | ||
| Ballast / displ. | 47.50 % | ||
| Displ. / length | 260.35 | ||
| Comfort ratio | 19.17 | ||
| Capsize | 2 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 19 ft | ||
| Maximum draft | 3.37 ft | ||
| Displacement | 4000 lbs | ||
| Ballast | 1900 lbs | ||
| Hull speed | 5.84 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 259 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 134.43 sq.ft | ||
| Sail area main | 125 sq.ft | ||
| I | 28.30 ft | ||
| J | 9.50 ft | ||
| P | 25 ft | ||
| E | 10 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Shannon Yachts | ||
| Designer | Ted Brewer | ||
| First built | 1976 | ||
| Last built | 1989 | ||
| Number built | 200 |
