Prelude 19
The Prelude 19 is a 19.25ft fractional sloop designed by Ian Proctor and built in fiberglass by Rydgeway Marine Ltd since 1971.
The Prelude 19 is a light sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Prelude 19 for sale elsewhere on the web:
Main features
| Model | Prelude 19 | ||
| Length | 19.25 ft | ||
| Beam | 6.83 ft | ||
| Draft | 2.25 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 33.53 | ||
| Ballast / displ. | 33.33 % | ||
| Displ. / length | 136.30 | ||
| Comfort ratio | 10.14 | ||
| Capsize | 2.39 |
Hull
| Hull type | Monohull twin Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 17 ft | ||
| Maximum draft | 2.25 ft | ||
| Displacement | 1500 lbs | ||
| Ballast | 500 lbs | ||
| Hull speed | 5.52 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 274 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Rydgeway Marine Ltd | ||
| Designer | Ian Proctor | ||
| First built | 1971 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
