The Pionier 930 is a 30.51ft masthead sloop designed by E. G. van de Stadt and built in fiberglass between 1976 and 1983.
The Pionier 930 is a heavy sailboat which is a good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Pionier 930 | ||
| Length | 30.51 ft | ||
| Beam | 9.61 ft | ||
| Draft | 5.58 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.83 | ||
| Ballast / displ. | 40.70 % | ||
| Displ. / length | 300.48 | ||
| Comfort ratio | 27.60 | ||
| Capsize | 1.82 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 24.15 ft | ||
| Maximum draft | 5.58 ft | ||
| Displacement | 9480 lbs | ||
| Ballast | 3858 lbs | ||
| Hull speed | 6.59 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 553.26 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 10 HP | ||
| Fuel capacity | 19 gals |
Accommodations
| Water capacity | 26 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | E. G. van de Stadt | ||
| First built | 1976 | ||
| Last built | 1983 | ||
| Number built | 0 | ?? |
