The Pion 30 is a 29.8ft fractional sloop designed by Van de Stadt and built in fiberglass by Friendship Yachts (NL) since 1971.
The Pion 30 is a moderate weight sailboat which is slightly under powered. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Pion 30 | ||
| Length | 29.80 ft | ||
| Beam | 9.50 ft | ||
| Draft | 6.30 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.23 | ||
| Ballast / displ. | 39.94 % | ||
| Displ. / length | 246.08 | ||
| Comfort ratio | 23.80 | ||
| Capsize | 1.90 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 24.44 ft | ||
| Maximum draft | 6.30 ft | ||
| Displacement | 8047 lbs | ||
| Ballast | 3214 lbs | ||
| Hull speed | 6.62 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 381 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 206.14 sq.ft | ||
| Sail area main | 175.18 sq.ft | ||
| I | 33.96 ft | ||
| J | 12.14 ft | ||
| P | 34.45 ft | ||
| E | 10.17 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Friendship Yachts (NL) | ||
| Designer | Van de Stadt | ||
| First built | 1971 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
