The Pilot 35 hinckley is a 35.75ft masthead sloop designed by Sparkman & Stephens and built in fiberglass by Hinckley Yachts between 1962 and 1975.
117 units have been built.
The Pilot 35 hinckley is a heavy sailboat which is slightly under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat.
Main features
| Model | Pilot 35 hinckley | ||
| Length | 35.75 ft | ||
| Beam | 9.50 ft | ||
| Draft | 5 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.42 | ||
| Ballast / displ. | 33.58 % | ||
| Displ. / length | 391.43 | ||
| Comfort ratio | 37.39 | ||
| Capsize | 1.59 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 25 ft | ||
| Maximum draft | 5 ft | ||
| Displacement | 13700 lbs | ||
| Ballast | 4600 lbs | ||
| Hull speed | 6.70 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 550 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 278.33 sq.ft | ||
| Sail area main | 271.87 sq.ft | ||
| I | 40.25 ft | ||
| J | 13.83 ft | ||
| P | 35.08 ft | ||
| E | 15.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 35 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hinckley Yachts | ||
| Designer | Sparkman & Stephens | ||
| First built | 1962 | ||
| Last built | 1975 | ||
| Number built | 117 |
Other photos
Pilot 35 hinckley for sale elsewhere on the web:
