The Pearson 390 is a 39.0ft cutter designed by William Shaw and built in fiberglass by Pearson Yachts between 1972 and 1973.
30 units have been built.
The Pearson 390 is a moderate weight sailboat which is slightly under powered. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Pearson 390 | ||
| Length | 39 ft | ||
| Beam | 13 ft | ||
| Draft | 4.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.17 | ||
| Ballast / displ. | 36.41 % | ||
| Displ. / length | 240.93 | ||
| Comfort ratio | 29.65 | ||
| Capsize | 1.90 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 33.67 ft | ||
| Maximum draft | 7.80 ft | ||
| Displacement | 20600 lbs | ||
| Ballast | 7500 lbs | ||
| Hull speed | 7.78 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 663 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 364.26 sq.ft | ||
| Sail area main | 307.50 sq.ft | ||
| I | 46.70 ft | ||
| J | 15.60 ft | ||
| P | 41 ft | ||
| E | 15 ft |
Engine
| Nb engines | 1 | ||
| Total power | 55 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Pearson Yachts | ||
| Designer | William Shaw | ||
| First built | 1972 | ||
| Last built | 1973 | ||
| Number built | 30 |
