The Passport 37 is a 37.0ft masthead sloop designed by Robert Perry and built in fiberglass by Passport Yachts between 1984 and 1988.
25 units have been built.
The Passport 37 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat.
Main features
| Model | Passport 37 | ||
| Length | 37 ft | ||
| Beam | 11.92 ft | ||
| Draft | 5.80 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.12 | ||
| Ballast / displ. | 37.44 % | ||
| Displ. / length | 298.23 | ||
| Comfort ratio | 31.07 | ||
| Capsize | 1.84 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 29.62 ft | ||
| Maximum draft | 5.80 ft | ||
| Displacement | 17360 lbs | ||
| Ballast | 6500 lbs | ||
| Hull speed | 7.29 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 673 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 384 sq.ft | ||
| Sail area main | 288.53 sq.ft | ||
| I | 48 ft | ||
| J | 16 ft | ||
| P | 43 ft | ||
| E | 13.42 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Passport Yachts | ||
| Designer | Robert Perry | ||
| First built | 1984 | ||
| Last built | 1988 | ||
| Number built | 25 |
