Pandora 700
The Pandora 700 is a 23.0ft masthead sloop designed by E. G. van de Stadt and built in fiberglass by Rydgeway Marine Ltd between 1976 and 1991.
The Pandora 700 is a light sailboat which is slightly under powered. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Pandora 700 for sale elsewhere on the web:
Main features
| Model | Pandora 700 | ||
| Length | 23 ft | ||
| Beam | 6.92 ft | ||
| Draft | 3.75 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.06 | ||
| Ballast / displ. | 39.20 % | ||
| Displ. / length | 169.31 | ||
| Comfort ratio | 14.66 | ||
| Capsize | 2.04 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 18.75 ft | ||
| Maximum draft | 3.75 ft | ||
| Displacement | 2500 lbs | ||
| Ballast | 980 lbs | ||
| Hull speed | 5.80 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 173 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 97.60 sq.ft | ||
| Sail area main | 75.19 sq.ft | ||
| I | 24.40 ft | ||
| J | 8 ft | ||
| P | 21.33 ft | ||
| E | 7.05 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Rydgeway Marine Ltd | ||
| Designer | E. G. van de Stadt | ||
| First built | 1976 | ||
| Last built | 1991 | ||
| Number built | 0 | ?? |
