The Packet cat 35 island packet is a 35.0ft fractional sloop designed by Bob Johnson and built in fiberglass by Island Packet Yachts between 1992 and 1997.
41 units have been built.
The Packet cat 35 island packet is a light sailboat which is a high performer. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Packet cat 35 island packet | ||
| Length | 35 ft | ||
| Beam | 15 ft | ||
| Draft | 2.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.91 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 187.32 | ||
| Comfort ratio | 16.29 | ||
| Capsize | 2.59 |
Hull
| Hull type | Catamaran Twin Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 31 ft | ||
| Maximum draft | 2.50 ft | ||
| Displacement | 12500 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 7.46 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 735 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 375.49 sq.ft | ||
| Sail area main | 228.67 sq.ft | ||
| I | 42.50 ft | ||
| J | 17.67 ft | ||
| P | 37.58 ft | ||
| E | 12.17 ft |
Engine
| Nb engines | 1 | ||
| Total power | 27 HP | ||
| Fuel capacity | 55 gals |
Accommodations
| Water capacity | 140 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Island Packet Yachts | ||
| Designer | Bob Johnson | ||
| First built | 1992 | ||
| Last built | 1997 | ||
| Number built | 41 |
