The Pacific seacraft 37 is a 36.92ft cutter designed by W.I.B. Crealock and built in fiberglass by Pacific Seacraft since 1980.
The Pacific seacraft 37 is a heavy sailboat which is slightly under powered. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Pacific seacraft 37 | ||
| Length | 36.92 ft | ||
| Beam | 10.83 ft | ||
| Draft | 5.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.63 | ||
| Ballast / displ. | 38.75 % | ||
| Displ. / length | 334.26 | ||
| Comfort ratio | 33.95 | ||
| Capsize | 1.72 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 27.75 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 16000 lbs | ||
| Ballast | 6200 lbs | ||
| Hull speed | 7.06 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 618 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 346.50 sq.ft | ||
| Sail area main | 271.96 sq.ft | ||
| I | 44 ft | ||
| J | 15.75 ft | ||
| P | 38.17 ft | ||
| E | 14.25 ft |
Engine
| Nb engines | 1 | ||
| Total power | 51 HP | ||
| Fuel capacity | 40 gals |
Accommodations
| Water capacity | 95 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Pacific Seacraft | ||
| Designer | W.I.B. Crealock | ||
| First built | 1980 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
