Oyster 575
The Oyster 575 is a 58.67ft masthead sloop designed by Rob Humphreys and built in fiberglass by Oyster Marine since 2010.
The Oyster 575 is a light sailboat which is a very high performer. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Oyster 575 for sale elsewhere on the web:
Main features
| Model | Oyster 575 | ||
| Length | 58.67 ft | ||
| Beam | 16.42 ft | ||
| Draft | 8.82 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.39 | ||
| Ballast / displ. | 30.56 % | ||
| Displ. / length | 190.94 | ||
| Comfort ratio | 40.52 | ||
| Capsize | 1.70 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 51.50 ft | ||
| Maximum draft | 8.82 ft | ||
| Displacement | 58422 lbs | ||
| Ballast | 17855 lbs | ||
| Hull speed | 9.62 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 2097 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 130 HP | ||
| Fuel capacity | 343 gals |
Accommodations
| Water capacity | 250 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Oyster Marine | ||
| Designer | Rob Humphreys | ||
| First built | 2010 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
