The Orion 27 2 pacific seacraft is a 30.92ft cutter designed by Henry Morschladt and built in fiberglass by Pacific Seacraft since 1979.
The Orion 27 2 pacific seacraft is a very heavy sailboat which is a reasonably good performer. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat.
Main features
| Model | Orion 27 2 pacific seacraft | ||
| Length | 30.92 ft | ||
| Beam | 9.25 ft | ||
| Draft | 4 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.57 | ||
| Ballast / displ. | 32 % | ||
| Displ. / length | 408.58 | ||
| Comfort ratio | 32.17 | ||
| Capsize | 1.72 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 22.19 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 10000 lbs | ||
| Ballast | 3200 lbs | ||
| Hull speed | 6.31 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 508 sq.ft | ||
| Air draft | 40.92 ft | ||
| Sail area fore | 252.66 sq.ft | ||
| Sail area main | 189.88 sq.ft | ||
| I | 36.75 ft | ||
| J | 13.75 ft | ||
| P | 31 ft | ||
| E | 12.25 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 6.08 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Pacific Seacraft | ||
| Designer | Henry Morschladt | ||
| First built | 1979 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
