The Omega 30 s is a 30.67ft fractional sloop designed by Ron Holland and built in fiberglass by Vindo (Nötesund Varv AB) between 1982 and 1986.
320 units have been built.
The Omega 30 s is a light sailboat which is a high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Omega 30 s | ||
| Length | 30.67 ft | ||
| Beam | 9.67 ft | ||
| Draft | 5.08 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.36 | ||
| Ballast / displ. | 41.24 % | ||
| Displ. / length | 173.11 | ||
| Comfort ratio | 19 | ||
| Capsize | 2.03 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 26.17 ft | ||
| Maximum draft | 5.08 ft | ||
| Displacement | 6950 lbs | ||
| Ballast | 2866 lbs | ||
| Hull speed | 6.85 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 462 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 204.70 sq.ft | ||
| Sail area main | 257.56 sq.ft | ||
| I | 35.60 ft | ||
| J | 11.50 ft | ||
| P | 37.60 ft | ||
| E | 13.70 ft |
Engine
| Nb engines | 1 | ||
| Total power | 6 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Vindo (Nötesund Varv AB) | ||
| Designer | Ron Holland | ||
| First built | 1982 | ||
| Last built | 1986 | ||
| Number built | 320 |
