The Olympic star is a 23.33ft masthead sloop designed by C. A. Martzoucos and built in fiberglass by Olympic Yachtcraft Corp. (CAN) since 1968.
The Olympic star is a heavy sailboat which is a reasonably good performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Olympic star | ||
| Length | 23.33 ft | ||
| Beam | 7.42 ft | ||
| Draft | 2.92 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.65 | ||
| Ballast / displ. | 38.96 % | ||
| Displ. / length | 316.34 | ||
| Comfort ratio | 21.34 | ||
| Capsize | 1.90 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 17.58 ft | ||
| Maximum draft | 2.92 ft | ||
| Displacement | 3850 lbs | ||
| Ballast | 1500 lbs | ||
| Hull speed | 5.62 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 255 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 113.40 sq.ft | ||
| Sail area main | 139.44 sq.ft | ||
| I | 27 ft | ||
| J | 8.40 ft | ||
| P | 25.75 ft | ||
| E | 10.83 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Olympic Yachtcraft Corp. (CAN) | ||
| Designer | C. A. Martzoucos | ||
| First built | 1968 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
