The Offshore 53 ms cheoy lee is a 52.75ft masthead ketch designed by John G. Alden Inc. and built in fiberglass by Cheoy Lee Shipyard since 1972.
The Offshore 53 ms cheoy lee is a heavy sailboat which is under powered. It is not stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Offshore 53 ms cheoy lee | ||
| Length | 52.75 ft | ||
| Beam | 15 ft | ||
| Draft | 6 ft | ||
| Country | Hong Kong (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 10.58 | ||
| Ballast / displ. | 28.15 % | ||
| Displ. / length | 339.14 | ||
| Comfort ratio | 55.19 | ||
| Capsize | 1.53 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 43 ft | ||
| Maximum draft | 6 ft | ||
| Displacement | 60400 lbs | ||
| Ballast | 17000 lbs | ||
| Hull speed | 8.79 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 1013 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 120 HP | ||
| Fuel capacity | 520 gals |
Accommodations
| Water capacity | 420 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Cheoy Lee Shipyard | ||
| Designer | John G. Alden Inc. | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
