The Norseman 400 grant is a 40.0ft masthead sloop designed by Gary Grant and built in fiberglass since 1980.
The Norseman 400 grant is a light sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Norseman 400 grant | ||
| Length | 40 ft | ||
| Beam | 13.33 ft | ||
| Draft | 5.33 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.28 | ||
| Ballast / displ. | 40 % | ||
| Displ. / length | 184.40 | ||
| Comfort ratio | 25.16 | ||
| Capsize | 2 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 35.83 ft | ||
| Maximum draft | 5.33 ft | ||
| Displacement | 19000 lbs | ||
| Ballast | 7600 lbs | ||
| Hull speed | 8.02 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 766 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 46 HP | ||
| Fuel capacity | 70 gals |
Accommodations
| Water capacity | 120 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Gary Grant | ||
| First built | 1980 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
