The Nonsuch 22 is a 22.0ft cat (unstayed) designed by Mark Ellis Design and built in fiberglass by Hinterhoeller Yachts Ltd. since 1984.
58 units have been built.
The Nonsuch 22 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Nonsuch 22 | ||
| Length | 22 ft | ||
| Beam | 8.50 ft | ||
| Draft | 3.67 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.79 | ||
| Ballast / displ. | 36 % | ||
| Displ. / length | 259.10 | ||
| Comfort ratio | 21.32 | ||
| Capsize | 1.99 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20.50 ft | ||
| Maximum draft | 3.67 ft | ||
| Displacement | 5000 lbs | ||
| Ballast | 1800 lbs | ||
| Hull speed | 6.07 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cat (unstayed) | ||
| Sail area (100%) | 306 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 15 gals |
Accommodations
| Water capacity | 23 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hinterhoeller Yachts Ltd. | ||
| Designer | Mark Ellis Design | ||
| First built | 1984 | ||
| Last built | 0 | ?? | |
| Number built | 58 |
