The Nimble voyager 26 is a 26.0ft cutter designed by Daniel J. Avoures and built in fiberglass by Nimble Boats Works Inc. (USA) since 1989.
The Nimble voyager 26 is a heavy sailboat which is a reasonably good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Nimble voyager 26 | ||
| Length | 26 ft | ||
| Beam | 8.25 ft | ||
| Draft | 3.33 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.26 | ||
| Ballast / displ. | 41.04 % | ||
| Displ. / length | 311.71 | ||
| Comfort ratio | 27.46 | ||
| Capsize | 1.75 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 21.25 ft | ||
| Maximum draft | 3.33 ft | ||
| Displacement | 6700 lbs | ||
| Ballast | 2750 lbs | ||
| Hull speed | 6.18 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 360 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 12 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 24 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Nimble Boats Works Inc. (USA) | ||
| Designer | Daniel J. Avoures | ||
| First built | 1989 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
