The Nicholson 35-1 is a 35.24ft masthead sloop designed by Ray Wall/Camper & Nicholson and built in fiberglass by Camper & Nicholson between 1971 and 1985.
200 units have been built.
The Nicholson 35-1 is a heavy sailboat which is a reasonably good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Nicholson 35-1 | ||
| Length | 35.24 ft | ||
| Beam | 10.43 ft | ||
| Draft | 5.51 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 36600 |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.92 | ||
| Ballast / displ. | 46.90 % | ||
| Displ. / length | 365 | ||
| Comfort ratio | 36.39 | ||
| Capsize | 1.67 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 26.74 ft | ||
| Maximum draft | 5.51 ft | ||
| Displacement | 15652.80 lbs | ||
| Ballast | 7341.38 lbs | ||
| Hull speed | 6.93 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 698.04 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 303.11 sq.ft | ||
| Sail area main | 234.01 sq.ft | ||
| I | 43.31 ft | ||
| J | 14.01 ft | ||
| P | 35.99 ft | ||
| E | 12.99 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 48 gals |
Accommodations
| Water capacity | 96 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Camper & Nicholson | ||
| Designer | Ray Wall/Camper & Nicholson | ||
| First built | 1971 | ||
| Last built | 1985 | ||
| Number built | 200 |
