The Bavaria 31 is a 32.75ft fractional sloop designed by J & J Design and built in fiberglass by Bavaria Yachts (GER) between 1999 and 2001.
It accomodates 6 people in 2 cabins plus salon.
The Bavaria 31 is a light sailboat which is a very high performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Bavaria 31 | ||
| Length | 32.75 ft | ||
| Beam | 9.75 ft | ||
| Draft | 5.67 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.04 | ||
| Ballast / displ. | 30.55 % | ||
| Displ. / length | 180.02 | ||
| Comfort ratio | 20.56 | ||
| Capsize | 1.96 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 27 ft | ||
| Maximum draft | 5.67 ft | ||
| Displacement | 7937 lbs | ||
| Ballast | 2425 lbs | ||
| Hull speed | 6.96 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 548 sq.ft | ||
| Air draft | 46.26 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 19 HP | ||
| Fuel capacity | 24 gals |
Accommodations
| Water capacity | 40 gals | ||
| Headroom | 5.97 ft | ||
| Nb of cabins | 2 | ||
| Nb of berths | 6 | ||
| Nb heads | 1 |
Builder data
| Builder | Bavaria Yachts (GER) | ||
| Designer | J & J Design | ||
| First built | 1999 | ||
| Last built | 2001 | ||
| Number built | 0 | ?? |
