The New york 36 is a 35.67ft fractional sloop designed by William Cook and built in fiberglass by Schock W.D. between 1980 and 1985.
88 units have been built.
The New york 36 is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | New york 36 | ||
| Length | 35.67 ft | ||
| Beam | 11.67 ft | ||
| Draft | 6.33 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.48 | ||
| Ballast / displ. | 42 % | ||
| Displ. / length | 183.05 | ||
| Comfort ratio | 18.90 | ||
| Capsize | 2.17 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 29 ft | ||
| Maximum draft | 6.33 ft | ||
| Displacement | 10000 lbs | ||
| Ballast | 4200 lbs | ||
| Hull speed | 7.22 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 650 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 274.56 sq.ft | ||
| Sail area main | 372 sq.ft | ||
| I | 42.90 ft | ||
| J | 12.80 ft | ||
| P | 46.50 ft | ||
| E | 16 ft |
Engine
| Nb engines | 1 | ||
| Total power | 13 HP | ||
| Fuel capacity | 20 gals |
Accommodations
| Water capacity | 40 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Schock W.D. | ||
| Designer | William Cook | ||
| First built | 1980 | ||
| Last built | 1985 | ||
| Number built | 88 |
