The Mumm 36 is a 35.83ft fractional sloop designed by Bruce Farr and built in carbon fiber or composite by Beneteau since 1993.
120 units have been built.
The Mumm 36 is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Mumm 36 | ||
| Length | 35.83 ft | ||
| Beam | 11.83 ft | ||
| Draft | 7.33 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 25.53 | ||
| Ballast / displ. | 42.94 % | ||
| Displ. / length | 113.68 | ||
| Comfort ratio | 14.22 | ||
| Capsize | 2.36 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 31.75 ft | ||
| Maximum draft | 7.33 ft | ||
| Displacement | 8150 lbs | ||
| Ballast | 3500 lbs | ||
| Hull speed | 7.55 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 644 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 275.31 sq.ft | ||
| Sail area main | 368.78 sq.ft | ||
| I | 43.70 ft | ||
| J | 12.60 ft | ||
| P | 44.70 ft | ||
| E | 16.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 40 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Beneteau | ||
| Designer | Bruce Farr | ||
| First built | 1993 | ||
| Last built | 0 | ?? | |
| Number built | 120 |
