The Morgan out island 33 is a 33.0ft masthead sloop designed by Charles Morgan and built in fiberglass by Morgan Yachts since 1973.
The Morgan out island 33 is a heavy sailboat which is slightly under powered. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Morgan out island 33 | ||
| Length | 33 ft | ||
| Beam | 11.83 ft | ||
| Draft | 3.92 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.10 | ||
| Ballast / displ. | 34.48 % | ||
| Displ. / length | 311.26 | ||
| Comfort ratio | 28.63 | ||
| Capsize | 1.94 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 27.50 ft | ||
| Maximum draft | 3.92 ft | ||
| Displacement | 14500 lbs | ||
| Ballast | 5000 lbs | ||
| Hull speed | 7.03 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 522 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 273.38 sq.ft | ||
| Sail area main | 248.50 sq.ft | ||
| I | 40.50 ft | ||
| J | 13.50 ft | ||
| P | 35.50 ft | ||
| E | 14 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Morgan Yachts | ||
| Designer | Charles Morgan | ||
| First built | 1973 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
