The Morgan 32 is a 31.92ft masthead sloop designed by Ted Brewer/Jack Corey and built in fiberglass by Morgan Yachts between 1980 and 1986.
The Morgan 32 is a heavy sailboat which is a reasonably good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a very short water supply range.
Main features
| Model | Morgan 32 | ||
| Length | 31.92 ft | ||
| Beam | 11.50 ft | ||
| Draft | 5.33 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16 | ||
| Ballast / displ. | 36.36 % | ||
| Displ. / length | 314.29 | ||
| Comfort ratio | 24.28 | ||
| Capsize | 2.07 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 25 ft | ||
| Maximum draft | 5.33 ft | ||
| Displacement | 11000 lbs | ||
| Ballast | 4000 lbs | ||
| Hull speed | 6.70 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 493 sq.ft | ||
| Air draft | 45.67 ft | ||
| Sail area fore | 276.60 sq.ft | ||
| Sail area main | 216 sq.ft | ||
| I | 41.50 ft | ||
| J | 13.33 ft | ||
| P | 36 ft | ||
| E | 12 ft |
Engine
| Nb engines | 1 | ||
| Total power | 20 HP | ||
| Fuel capacity | 27 gals |
Accommodations
| Water capacity | 35 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Morgan Yachts | ||
| Designer | Ted Brewer/Jack Corey | ||
| First built | 1980 | ||
| Last built | 1986 | ||
| Number built | 0 | ?? |
