The Morgan 2425 is a 24.92ft masthead sloop designed by Charles Morgan Jr. and built in fiberglass by Morgan Yachts between 1965 and 1976.
460 units have been built.
The Morgan 2425 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. There is a very short water supply range.
Main features
| Model | Morgan 2425 | ||
| Length | 24.92 ft | ||
| Beam | 8 ft | ||
| Draft | 2.80 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.02 | ||
| Ballast / displ. | 38.78 % | ||
| Displ. / length | 220.11 | ||
| Comfort ratio | 21.06 | ||
| Capsize | 1.89 |
Hull
| Hull type | Monohull keel and centerboard with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21.50 ft | ||
| Maximum draft | 7 ft | ||
| Displacement | 4900 lbs | ||
| Ballast | 1900 lbs | ||
| Hull speed | 6.21 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 306 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 151.13 sq.ft | ||
| Sail area main | 155.25 sq.ft | ||
| I | 31 ft | ||
| J | 9.75 ft | ||
| P | 27 ft | ||
| E | 11.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Morgan Yachts | ||
| Designer | Charles Morgan Jr. | ||
| First built | 1965 | ||
| Last built | 1976 | ||
| Number built | 460 |
