The Moody 422 is a 40.67ft masthead sloop designed by Bill Dixon and built in fiberglass by Moody Yachts (A. H. Moody & Sons) since 1986.
The Moody 422 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Moody 422 | ||
| Length | 40.67 ft | ||
| Beam | 13.25 ft | ||
| Draft | 5.75 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.46 | ||
| Ballast / displ. | 40 % | ||
| Displ. / length | 235.19 | ||
| Comfort ratio | 28.78 | ||
| Capsize | 1.92 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 34.16 ft | ||
| Maximum draft | 5.75 ft | ||
| Displacement | 21000 lbs | ||
| Ballast | 8400 lbs | ||
| Hull speed | 7.83 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 780 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 426.28 sq.ft | ||
| Sail area main | 353.94 sq.ft | ||
| I | 51.67 ft | ||
| J | 16.50 ft | ||
| P | 45.67 ft | ||
| E | 15.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 50 HP | ||
| Fuel capacity | 70 gals |
Accommodations
| Water capacity | 110 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Moody Yachts (A. H. Moody & Sons) | ||
| Designer | Bill Dixon | ||
| First built | 1986 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
