Moody 37
The Moody 37 is a 37.0ft masthead sloop designed by Bill Dixon and built in fiberglass by Moody Yachts (A. H. Moody & Sons) between 1985 and 1987.
310 units have been built.
The Moody 37 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a short water supply range.
Moody 37 for sale elsewhere on the web:
Main features
| Model | Moody 37 | ||
| Length | 37 ft | ||
| Beam | 12.50 ft | ||
| Draft | 5.50 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.17 | ||
| Ballast / displ. | 40 % | ||
| Displ. / length | 237.71 | ||
| Comfort ratio | 26.36 | ||
| Capsize | 1.98 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 31.25 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 16250 lbs | ||
| Ballast | 6500 lbs | ||
| Hull speed | 7.49 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 646 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 352.50 sq.ft | ||
| Sail area main | 293.23 sq.ft | ||
| I | 47 ft | ||
| J | 15 ft | ||
| P | 41.30 ft | ||
| E | 14.20 ft |
Engine
| Nb engines | 1 | ||
| Total power | 35 HP | ||
| Fuel capacity | 53 gals |
Accommodations
| Water capacity | 66 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Moody Yachts (A. H. Moody & Sons) | ||
| Designer | Bill Dixon | ||
| First built | 1985 | ||
| Last built | 1987 | ||
| Number built | 310 |
